| 外径加工范围 / OD range | Ø2~Ø100 mm Max. |
|---|---|
| 厚度加工范围 / Thickness range | 15 mm Max. |
| 加工转速 / Speed (Lens spindle) | 0.6~300 rpm |
| 磨轮轴转速 / Speed (Wheel spindle) | 3000~4600 rpm |
| 磨轮规格 / Grinding Wheel Spec. | OD Ø160，ID Ø30H6 |
| 夹具规格 / Jig Spec. | M12x1.5mm |
| 电源规格 / Power | 220VAC 3P 50/60Hz |
| 空压源 / Air supply | 0.49 Mpa (5kg/cm²) Min. |
| 机台尺寸 / Machine Dimension | 1240x570x1770 mm |
| 机台重量 / Weight | 550 kg |
